The most common ceramic material used in hard armor plates. Alumina is prized for its high hardness-to-cost ratio. When a high-velocity projectile hits an Alumina ceramic face, the ceramic shatters the bullet while the ceramic itself breaks apart, dissipating energy.

Why it matters: Most affordable Level IV plates utilize Alumina, though they are generally heavier than Silicon Carbide or Boron Carbide alternatives.

A class of heat-resistant and strong synthetic fibers (like Kevlar or Twaron). These fibers are woven or laminated to create flexible soft armor panels. They work by "catching" a bullet in a multi-layered web of high-tensile strength strands.

Why it matters: Aramids are the backbone of concealable vests and provide the primary protection against handgun threats.

A measure of the weight of armor relative to its surface area, typically expressed in pounds per square foot (lb/ft²) or kilograms per square meter (kg/m²).

Why it matters: Lower areal density means a lighter vest for the same level of protection, which is critical for operator mobility and comfort.

The "dent" or indentation depth made in a non-hardening clay backing behind an armor panel during ballistic testing. It represents the energy transfer from the projectile to the wearer's body.

Why it matters: The NIJ limit is 44mm. Even if a vest stops a bullet, excessive BFD can cause fatal internal organ damage or broken ribs.

A thick, tough synthetic fabric (originally developed by DuPont) used for the exterior of plate carriers and tactical vests. It is highly resistant to abrasion and tearing but does not provide ballistic protection on its own.

One of the hardest materials on earth, used in premium, ultra-lightweight ceramic armor plates. It is significantly lighter than Alumina.

Why it matters: Boron Carbide is typically reserved for specialized military applications due to its high manufacturing cost.

The fabric garment designed to hold ballistic plates or soft armor panels. Carriers often feature MOLLE (Modular Lightweight Load-carrying Equipment) webbing for attaching pouches and accessories.

A hard armor insert made of ceramic materials. These are designed to stop high-velocity rifle rounds by destroying the projectile on impact.

Soft armor designed to be worn under a standard uniform or civilian clothing. These are usually rated for handgun threats (Level II or IIIA / HG1 or HG2).

The U.S. Military standard for ballistic plates, offering protection against armor-piercing rifle rounds. They follow specific sizing and curvature requirements (Small, Medium, Large, XL).

A projectile consisting of a soft core (usually lead) encased in a shell of harder metal (usually copper). FMJ rounds are a standard testing round for NIJ HG1 and HG2 levels.

Rigid plates (ceramic, steel, or UHMWPE) designed to protect against rifle threats. Unlike soft armor, hard armor does not flex.

The new NIJ 0101.07 designations for Handgun protection. HG1 replaces Level II, while HG2 replaces Level IIIA. HG2 is tested against faster 9mm and .44 Magnum rounds.

Rifle-rated armor designed to stop 7.62mm FMJ (non-armor-piercing) lead core rifle ammunition.

The highest rated armor level under the .06 standard. Level IV is designed to stop armor-piercing (AP) rifle rounds, such as the .30-06 M2 AP.

Context: Body Armor Megastore specializes in Level IV plates, offering the maximum level of personal protection available to citizens.

A 5.56x45mm NATO cartridge with a 62-grain bullet containing a steel penetrator tip. It is notoriously difficult for pure UHMWPE armor to stop due to its high velocity and steel core.

Why it matters: When shopping for rifle plates, ensure they are "Special Threat Rated" or RF2/RF3 if you expect M855 threats.

The ability of an armor plate to stop more than one ballistic impact within a specified proximity. While steel and PE have high multi-hit capability, ceramics are more susceptible to cracking, though modern composite ceramics are vastly improved.

The research, development, and evaluation agency of the U.S. Department of Justice. They set the gold standard for body armor testing and certification in the United States.

The material behind the ceramic strike-face of a plate, usually made of layers of UHMWPE or Aramid. It catches the fragments of the bullet and the ceramic after the initial impact.

The new NIJ 0101.07 designations for Rifle protection.

• RF1: Replaces Level III (7.62x51mm FMJ).
• RF2: An intermediate level that adds protection against the M855 "Green Tip."
• RF3: Replaces Level IV (Armor Piercing .30-06 M2 AP).

Small Arms Protective Insert cut. A plate shape with clipped top corners, designed to allow the wearer better range of motion for their arms when shouldering a rifle.

Ballistic panels made of flexible, woven materials. They are lighter and more comfortable than hard armor but are generally only effective against handgun rounds and fragmentation.

The fragmentation of a projectile (and sometimes the armor itself) upon impact with a hard surface, like a steel plate. These fragments can travel upward into the neck or downward into the legs.

Why it matters: Steel plates often require a "frag coating" or a "spall sleeve" to mitigate this risk.

A rating indicating protection against edged or pointed weapons (knives and spikes). Ballistic armor is not automatically stab-resistant unless specifically rated for it.

A non-ballistic pad worn behind a ballistic plate or panel. Its sole purpose is to further reduce Backface Deformation and absorb the kinetic energy (blunt force) of an impact.

A type of polyolefin plastic with extremely long polymer chains. When layered and pressed, it creates an incredibly strong, lightweight material that is 15 times stronger than steel by weight.

Why it matters: UHMWPE plates are buoyant (float in water) and offer excellent multi-hit protection against standard lead-core rifle rounds.

The velocity at which a specific projectile has a 50% chance of penetrating an armor panel and a 50% chance of being stopped.

Why it matters: V50 testing helps manufacturers determine the absolute limit of their armor's performance beyond the standard pass/fail NIJ certification.
